GT2 timing belt 6mm Rubber open loop belt for 3D printer

GT2 timing belt 6mm Rubber for 3D printer:

• Featuring a toothed design, the GT2 timing pulley and belt ensures accurate and smooth power transmission. It is commonly used in various industries, including robotics, 3D printing, CNC machines, and automation systems.
• gt2 Timing belt width of the belt provides a balance between strength and flexibility, making it suitable for a wide range of applications. Whether you need to transfer power or control the movement of mechanical components, the GT2 timing belt is a reliable choice.
• The open loop design of the belt allows for easy installation and adjustment. It can be easily cut to the desired length and secured using belt clamps or tensioners. This flexibility makes it ideal for custom projects and applications with unique requirements.
• Manufactured from high-quality rubber, the GT2 timing belt offers excellent resistance to wear, chemicals, and temperature variations. It is designed to withstand heavy loads and provide long-lasting performance.
• Invest in the GT2 timing belt for your precision timing needs. Its 6mm width, rubber construction, and open loop design ensure reliable and efficient power transmission in a variety of applications.

GT2 belt properties:

• The Power grip GT2 system is an extension of the HTD system with greater load-carrying capacity. HTD was developed for high torque drive applications.
• Circular arc tooth profile and tooth space is small.
• It is suitable for straight line driving.

Specifications:

• Pitch: 2mm
• Material: Neoprene Rubber With Fiberglass Core
• Width: 6mm
• Total Length: It will come in continuous Length (example: 1 meter x 5 pieces, will come in 5 meter single roll)
• Shape: Open Loop
• Core Wire Material: Glass Fiber
• Breaking Strength: 85 N Per 1 mm(61 lbf per 1/8 inch)
• Belt Width; Working Tension:110 N for 25.4 mm Belt width(24 lbf for 1 inch.)
• Temperature Range:-34°C to +85°C(-30°F to + 185°F)

Applications:

• 3D printer
• Automation
• Robotics, etc.

Package Include:

• gt2 Timing belt 6mm rubber belts (Multiple length added to cart will be given in single roll only)
• Example: 1 meter x 5 pieces, will come in 5 meter single roll
