E3D Revo micro 24V single nozzle kit 1.75mm filament for 3d printer machine (Original)

E3D Revo Micro 24V single nozzle kit 1.75mm filament for 3d printer machine (Original)

Features of E3D Revo Micro :

• Max temp: 300C
• Weight: 30g
• Nozzle type: Rapid Change Revo
• Maximum temp: 300°C
• M12 x 1.5 thread mounting
• Compatible with Bowden and direct drive systems

Description :

• Ready for Revo. Change nozzles at room temperature using just your fingers. No complex tools, no hot tightening. Revo Nozzles are a factory sealed nozzle and heat break in one, so they’re easy to fit and can’t leak material when in use.
• New hotness. A Revo Heater Core heats up in seconds. It’s much safer too – unlike other solutions on the market, a positive temperature coefficient (PTC) means the Revo Heater Core can not melt at extreme temperatures: power reduces as it gets hotter, so hazards are reduced in the event of a thermal runaway.
• Runs cool, looks cool. With an anodised black heatsink, Revo Micro not only runs cool but also looks cool.
• Flexible to any setup. Revo Micro plays nice with Bowden and direct drive setups, but its lightweight construction makes it an ideal choice for Bowden setups.

Please note:

• This kit does not include any 3D printed mounts
• The Revo Micro fan must be connected using the 5V regulator unless connecting directly to a 5V pin
• This kit comes with 100mm of PTFE tube if you require additional length see here
• You may need to adjust your Z offset when changing nozzles.

Kit Includes:

• 1 x Revo Micro heatsink
• 1 x M12 x 1.5 nut
• 1 x 20 x 20 x 10 5V fan
• 1 x 24V to 5V regulator board
• 1 x Revo Micro fan duct
• 1 x Collet
• 1 x Collet clip
• 1 x Revo Heater Core  24V
• 1 x Revo Heater Core spring
• 1 x Extension cable kit
• 1 x 100mm PTFE

Single nozzle kit:

• 1 x 0.40mm brass Revo Nozzle
