Bigtreetech Pi V1.2 Control Board For 3D Printer Parts

Bigtreetech Pi V1.2 Control Board For 3D Printer Parts

The Bigtreetech Pi V1.2 Control Board is designed to enhance the functionality and versatility of 3D printers. It integrates with the Raspberry Pi, allowing advanced control, expanded connectivity, and improved performance for 3D printing setups.

Specifications of Bigtreetech Pi V1.2

• Microcontroller: Powered by a Raspberry Pi (supports Raspberry Pi 4, 3B, 3B+)
• Power Supply: Supports 5V input via USB-C or Micro-USB for Raspberry Pi; separate power input for motor control and peripherals.
• GPIO (General Purpose Input/Output): Provides multiple GPIO pins for additional peripherals or sensors.
• Communication: Features UART, I2C, and SPI for communication with other electronics (such as extruders, stepper drivers, etc.).
• Connectors: Includes a variety of ports for stepper motors, endstops, heated beds, and extruders.
• Software Compatibility: Compatible with various 3D printer firmware such as Marlin, Klipper, or other Raspberry Pi-based control systems.
• Operating System: Compatible with Raspberry Pi OS (Raspbian) and other Linux-based operating systems.
• WiFi Connectivity: Supports wireless control through network interfaces (Ethernet or Wi-Fi, depending on the Raspberry Pi model used).
• Mounting: Compatible with standard 3D printer frame mounts and includes mounting holes.

Features of Bigtreetech Pi V1.2

• Raspberry Pi Integration: Leverages the power of Raspberry Pi to enable advanced control, real-time monitoring, and more flexibility than traditional 3D printer controllers.
• Enhanced Connectivity: The board offers several ways to connect to a 3D printer, including GPIO, UART, I2C, and SPI, making it versatile for a wide variety of 3D printing setups.
• High-Performance Processing: Supports multi-threaded operations and faster response times by utilizing the Raspberry Pi’s processing power, allowing you to run advanced features like web-based UIs, real-time feedback, and sensor integration.
• Klipper and Marlin Support: The Pi V1.2 board is compatible with popular firmware options like Klipper, providing improved motion control algorithms, smoother prints, and faster performance.
• Wi-Fi and Ethernet Support: With Raspberry Pi’s built-in Wi-Fi and Ethernet capabilities, you can control your 3D printer remotely via your local network or the internet for ease of use.
• Easy Firmware Updates: The Raspberry Pi-based setup allows for easy firmware and software updates, ensuring you can always benefit from the latest features, bug fixes, and improvements.
• Customizable Control: The board allows for significant customization, with the ability to add custom scripts, integrate sensors (like filament run-out, auto-bed leveling, etc.), and adjust settings through the web interface.
• Dual Motor Driver Support: Some configurations of the Pi V1.2 support dual stepper motor drivers for complex motion control (such as for multi-extruder systems).
• Onboard LCD Control: Offers integrated support for LCD touchscreens (such as the BTT TFT series) for direct control of the 3D printer.
• High Expandability: Additional expansion boards and accessories, such as the BTT Mini or Smart Controller, can be easily added to increase functionality.

Package Includes

• BTT Pi V1.2 Control Board x 1
