Volcano print J head Upgrade E3D V6 Hot End full metal Copper Hot end for 1.75mm Remote bowden Extruder 0.4 mm nozzle for 3d printer

Volcano print J head Upgrade E3D V6 Hot End full metal Copper Hot end for 1.75mm Remote bowden Extruder 0.4 mm nozzle for 3d printer

Volcano print J head Upgrade E3D V6 Hot End full metal Copper Hot end for 1.75mm Remote bowden Extruder 0.4 mm nozzle for 3d printer

• High Quality Printing: We’ve kept our sharp thermal transition that gives the high quality printing performance users have come to expect from E3D HotEnds.
• A sharp thermal break gives control over filament output so you get more immediate start and stops when extruding as well as retracts that are more effective in combating ooze.
• This means sharper, more accurate prints that have less stringing, oozing or blobbing.
• Adaptable: The V6 is a fully-integrated part of the E3D Ecosystem. Our range of nozzles and blocks gives you more opportunity to choose how you want to print.
• Choose from different filament diameters and materials to take your printing to the next level, and upgrade for ultra high-temperature printing.


Specifications

• Product name: Volcano J‑Head (E3D V6 upgrade)
• Voltage: 12V / 24V (select correct version)
• Filament: 1.75mm
• Feeding: Bowden (long-distance)
• Heat block size: 24 × 20 × 11.5 mm
• Heater: 40W, 1 m cable length
  Cooling fan: 30 × 30 × 10 mm, 24V, 2‑pin, with bracket

Features

• Name: Volcano J-head
• Rated Voltage：12V/24V.
• Feeder Long distance feeder.(Bowden)
• Heat Block Size: 24x20x11.5mm
• Nozzle Size：0.6mm,0.8mm,1.0mm,1.2mm for 1.75mm
• Heater wire：4V,40W,Length 1 meter.
• Cooling fan：30*30*10mm, 24V,2Pin, with Bracket.
• Throat tube: Bore 1.75mm, Radiating End Thread: M7, Heating End Thread: M6 ,length 22mm without Teflon tube.

 benefits

• Full‑metal hotend for broader material capability (with proper temps)
• Sharp thermal break for cleaner retractions and less oozing/stringing
• Volcano-style heat block for higher flow and larger prints
• Remote Bowden (long-distance feeder) support for 1.75mm filament
• 12V or 24V options to match your printer power system
• Compatible with E3D V6 ecosystem upgrades

Package Includs

• 1 Piece of Volcano J-head Upgrade E3D V6 Hot End
