Filament welder connector 3D printer filament connector 1.75mm PLA ABS filament sensor for all kind 1.75mm filament DIY multicolor filament 3D printer

3 reviews
Availability:

In stock


499.00

In stock

Filament welder connector 3D printer filament connector 1.75mm PLA ABS filament sensor for all kind 1.75mm filament DIY multicolor filament 3D printer

Filament welder connector 3D printer filament connector 1.75mm PLA ABS filament sensor for all kind 1.75mm filament

Features of Filament welder connector:

  • Wide Application: The filament welder connector is suit for most kind of 1.75mm filament: PLA/ ABS/ PETG/ PC/ PP/ PVB / HIPS, etc.
  • Effectively Save Filament: If the filament is disconnected during printing, or there is excess material after printing, which is not enough to print a model,it can be connected to continue printing.
  • And multi-level models can be printed in different colors with the same filament attached.
  • Filament Welder Connector Material: All-metal 3d printer filament connector using all-metal materials, high quality and durable, innovative design, easy to use.
  • Notes: 3d printer filament often lose water and become brittle when exposed to the air for a long time.
  • To prevent the filament from becoming brittle, please keep it sealed.

How to use

  1. Trim the two filament heads that need to connected.
  2. One end pass-through from the direction of the big end of the filament welder to the tick mark.
  3. The other end pass-through from the direction of the small head to the exposed 1-2mm.
  4. Burn with fire for 5-7 seconds. (This time is mainly for ordinary pla, abs, other harder filament should be slightly longer)
  5. Then quickly push the filament from the small end into the small hole at the big end, slowly (must not be fast).
  6. Then slowly pull back when the joint exposed, back and forth several times.
  7. After the filament completely cooled, the filament is completely pushed out from the small head end until it can be easily trimmed.
  8. Test the results after the repair completed (carefully bend the joint – straighten – bend – straighten).
  9. If you hear a crisp sound, we need to weld again.
  10. Unscrew the bolt at one end of the waist groove the connecting piece with, take out the filament, and assemble the filament welder for the next use.

Note

  • The hardness of the filament of different materials is different.
  • The harder the material is, the longer the burning time is.
  • Do not wait until the end of the filament is very close to the extruder
Advantage
  • Made of metal material, high quality´╝îinnovative design, easy to use
  • You can connect the filament with this connector in two colors of the 1.75mm filament.
  • Suitable for PLA ,ABS filament
Package Include:
  • 1 piece of filament connector ( as per order )





Weight 50 g
